MG9 Series

MG9 Series

  • Upgraded version of flagship rental LED screen
  • Pixel pitch: 2.9 / 3.9 / 5.9mm
  • Dimension: 500*500*71mm
  • Operating environment: Indoor & Outdoor
Request A Solution
Pixel Pitch (mm)2.93.93.95.9
Operating EnvironmentIndoor & OutdoorIndoor & OutdoorIndoor & OutdoorIndoor & Outdoor
Module Size (mm)250*250250*250250*250250*250
Cabinet Size (mm)500*500*71500*500*71500*500*71500*500*71
Cabinet Resolution (W×H)168*168128*128128*12884*84
IP GradeFront IP65 Rear IP54Front IP65 Rear IP54Front IP65 Rear IP54Front IP65 Rear IP54
Weight (kg/Cabinet)6.3665.9
White Balance Brightness (nit)3500-3800 / 4000-45004000-4200 / 5000-55003200-3500 / 4000-42003000-3500 / 4000-4500
Horizontal/Vertical Viewing Angle ( °)160/160160/160160/160160/120
Power Consumption (W/m²)700±15%/235±15%700±15%/235±15%550±15%/180±15%700±15%/235±15%
Refresh Rate (Hz)≥3840≥3840≥3840≥3840
Control SystemNovaNovaNovaNova
Product CertificationCE,FCC,ETLCE,FCC,ETLCE,FCC,ETLCE,FCC,ETL
