MG10 Series
- New Upgrade Indoor Rental Series
- Pixel pitch: 1.9 / 2.6 / 3.9 / 4.8
- Dimension: 500 × 500 × 71mm
- Operating environment: Indoor
| Pixel Pitch (mm) | 1.9 | 1.9 | 2.6 | 2.6 | 3.9 | 4.8 |
| Operating Environment | Indoor | Indoor | Indoor | Indoor | Indoor | Indoor |
| Module Size (mm) | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 |
| Cabinet Size (mm) | 500*500*71 | 500*500*71 | 500*500*71 | 500*500*71 | 500*500*71 | 500*500*71 |
| Cabinet Resolution (W×H) | 256*256 | 256*256 | 192*192 | 192*192 | 128*128 | 104*104 |
| IP Grade | IP50 | IP50 | IP50 | IP50 | IP50 | IP50 |
| Weight (kg/Cabinet) | 6.6 | 6.6 | 6.6 | 6.6 | 6.6 | 6.6 |
| White Balance Brightness (nit) | 800~1000 | 1000~1200 | 800-1000 | 1000-1200 | 800~1000 | 800-1000 |
| Horizontal/Vertical Viewing Angle ( °) | 160/160 | 160/160 | 160/140 | 160/140 | 160/140 | 160/140 |
| Power Consumption (W/m²) | 450±15%/150±15% | 560±15%/190±15% | 450±15%/150±15% | 560±15%/190±15% | 420±15%/140±15% | 420±15%/140±15% |
| Refresh Rate (Hz) | ≥3840(3840, 7680...) | ≥3840(3840, 7680...) | ≥3840(3840, 7680...) | ≥3840(3840, 7680...) | ≥3840(3840, 7680...) | ≥3840(3840, 7680...) |
| Control System | Nova | Nova | Nova | Nova | Nova | Nova |
| Product Certification | CE,FCC,ETL | CE,FCC,ETL | CE,FCC,ETL | CE,FCC,ETL | CE,FCC,ETL | CE,FCC,ETL |
