MU Series
- Fast large screen installation
- Pixel pitch: 1.9 / 2.6 / 2.9 / 3.9 / 4.8mm
- Dimension: 500*500*73mm / 500*1000*73mm
- Operating environment: Indoor & Outdoor
| Pixel Pitch (mm) | 1.9 | 2.6 | 3.9 | 4.8 | 2.9 | 3.9 |
| Operating Environment | Indoor | Indoor | Indoor | Indoor | Indoor & Outdoor | Indoor & Outdoor |
| Module Size (mm) | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 |
| Cabinet Size (mm) | 500*500*73 | 500*500*73 / 500*1000*73 | 500*500*73 / 500*1000*73 | 500*500*73 / 500*1000*73 | 500*500*73 / 500*1000*73 | 500*500*73 / 500*1000*73 |
| Cabinet Resolution (W×H) | 256*256 | 192×192 / 192×384 | 128×128 / 128×256 | 104*104 / 104×208 | 168*168 / 168*336 | 128*128 / 128*256 |
| IP Grade | IP50 | IP50 | IP50 | IP50 | IP65 | IP65 |
| Weight (kg/Cabinet) | 7.6 | 7.6/12.6 | 7.6/12.6 | 7.6/12.6 | 7.6/12.6 | 7.6/12.6 |
| White Balance Brightness (nit) | 1200-1500 | 800-1000 | 800-1000 | 800-1000 | 3500-3800 | 4000-4200 |
| Horizontal/Vertical Viewing Angle ( °) | 160/120 | 160/120 | 160/120 | 160/120 | 160/120 | 160/160 |
| Power Consumption (W/m²) | 650±15% / 220±15% | 450±15% / 150±15% | 420±15% / 140±15% | 420±15% / 140±15% | 700±15% / 235±15% | 700±15% / 235±15% |
| Refresh Rate (Hz) | ≥3840 | ≥3840 | ≥3840 | ≥3840 | ≥3840 | ≥3840 |
| Control System | Nova | Nova | Nova | Nova | Nova | Nova |
| Certification | CE, FCC, ETL | CE, FCC, ETL | CE, FCC, ETL | CE, FCC, ETL | CE, FCC, ETL | CE, FCC, ETL |
