Mair Series
- Outdoor Rental Transparent LED Display
- Pixel pitch: 5.95 / 7.8 mm
- Dimension: 1000 × 1000 × 102 mm
- Operating environment: Outdoor
| Pixel Pitch (mm) | 5.95 | 7.81 |
| Operating Environment | Outdoor | Outdoor |
| Module Size (mm) | 500*250 | 500*250 |
| Cabinet Size (mm) | 1000*1000*102 | 1000*1000*102 |
| Module Resolution (WxH) | 168*168 | 128*128 |
| IP Grade | IP65 | IP65 |
| Weight (kg/Cabinet) | 19 | 19 |
| White Balance Brightness (nit) | 3000~3500 / 4000~4500 | 3000~3500 / 4000~4500 |
| Horizontal/Vertical Viewing Angle ( °) | 160/140 | 160/140 |
| Power Consumption (W/m²) | 500±15% / 167±15% | 500±15% / 167±15% |
| Refresh Rate (Hz) | ≥7680 | ≥7680 |
| Control System | Nova/Brompton | Nova/Brompton |
| Product Certification | CE,FCC,ETL | CE,FCC,ETL |
